Specifications
Drivetrain
Chain
KMC
Cassette
SHIMANO
Rear Derailleur
SHIMANO
Shift Levers
Sunrace
Bottom Bracket
Square-tapered, 68mm, internal bearings, 122.5mm spindle
Crankset
Alloy Tripple 28/38/48
Frameset
Seat Binder
Alloy, quick release
Frame
Totem premium alloy, internal cable routing, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper
Suspension
Fork
SR Suntour Totem 29, 30mm stanchions, Rx Tune, coil spring, QR, 90/100mm travel, 42mm offset
Brakes
Front Brake
Shimano Disc, 160mm
Rear Brake
Shimano Disc, 160mm
Wheels & tires
Front Tire
29x2.10"
Rear Tire
29x2.10"
Front Hub
Formula SP-2120 6-Bolt, disc, 100x9mm spacing, quick-release
Rear Hub
Formula SP-2125, 6-Bolt freehub, disc, 135x9mm spacing, quick-release
Rims
Alloy, disc only, double-wall, 25mm inner width, 32h
Spokes
Stainless, 14g
Inner Tubes
Standard 40mm SV 650B/29x1.75-2.4
Cockpit
Stem
3D-forged alloy, 31.8mm, 7-degree rise
SeatPost
Alloy
Saddle
Totem Steel rails
Grips
Trail Grips
Handlebars
Totem Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
